Matte Black Air-Cooled Beer Tower with Drip Tray – Single Faucet

This set gives you a complete pour point for a single tap. The Axis Tower has a curved, spout-style design that stands out on a counter without taking up more room than a standard straight tower, making it a strong fit for tighter spaces like an apartment kegerator, a small home bar corner, or a compact commercial counter. Beneath the faucet, the 12″ x 5″ drip tray catches drips, foam, and glass rinse-off, keeping the counter clean during regular use. Both pieces are finished in the same black matte, giving the whole setup a clean, coordinated look right out of the box.

Overview

• Single-tap, air-cooled beer tower finished in matte black
• Paired with a 12″ x 5″ surface-mount drip tray in the same finish
• Built for kegerators, home bars, and compact commercial counters
• Curved spout design takes up less space than a standard straight tower



Tower:

Size & Dimensions

• Overall height: 19″ (484 mm)
• Spout height: 14.7″ (374 mm)
• Spout reach (front projection): 7″ (178 mm)
• Base diameter: 2.9″ (74 mm)
• Shank thread: 5/8″ x 14 BSP
• Beer line length: 5 feet

Mounting & Installation

• Mounts through a counter/kegerator top via a through-hole cutout
• Requires a shank sized for 5/8″ x 14 BSP threading
• Comes with a 5 ft. length of NSF-approved clear PVC beer tubing — enough for most standard kegerator and under-counter cooler depths
• Best performance when mounted directly on or very close to the cold air source (kegerator/cooler), since this is an air-cooled system — not recommended for tap runs several feet away from the cooler

Build & Materials

• Body: high-quality brass
• Faucet: 304 stainless steel
• Finish: matte black powder coat (baked-on, not painted — resists chipping and peeling)
• Beer tubing: NSF-approved clear PVC

Drip Tray:

Size & Dimensions

• Length x Width: 12″ x 5″
• Depth: 3/4″
• Overall height (with drain fitting): ~2.5″
• Drain position: centered, 6″ from the tray edge
• Drain size: 3-1/2″ x 1/2″ ID, threaded brass

Mounting & Installation

• Surface-mount design — sits on top of the counter, no cutting required for the tray body
• Drain is center-mounted and comes with a solid brass threaded fitting (3-1/2″ x 1/2″ ID)
• If plumbing a drain line: connect to the 1/2″ ID threaded brass fitting and route to a floor drain or waste line
• No drain access available? Cap the fitting and empty the tray manually instead

Build & Materials

• Fabricated from 1.2 mm (18-gauge) stainless steel for durability
• Finish: matte black (base model available in brushed stainless as well)
• Removable grill — lifts out for manual rinsing, no scrubbing around a fixed grate
• NSF certified

Drip Tray And Tower could be purchased separately too.
